Factory Direct Poultry Egg Packing Machine In Malaysia

Factory Direct Poultry Egg Packing Machine – Malaysia

A poultry egg packing machine automates the collection, orientation, and placement of eggs into trays or cartons at high speed while minimizing shell damage.

Technical Specifications

The machine is designed for continuous operation in egg processing lines, handling sizes from small to large eggs with adjustable lane widths.

Parameter	Typical Value
Maximum capacity	Up to 30,000 eggs per hour (depending on egg size and lane count)
Egg size range	Small (40 g) to Jumbo (70 g)
Lane width adjustment	30 mm – 45 mm manual sliding guides
Power consumption	1.5 kW average at full load
Motor rating	0.75 kW servo‑driven orientator
Overall dimensions (L×W×H)	2200 mm × 950 mm × 1500 mm (customizable)
Net weight	Approx. 850 kg
Contact material	AISI 304 stainless steel, FDA‑grade
Control system	PLC with touch‑screen HMI, recipe storage
Optional features	UV sterilization lane, automatic tray ejector, data logging

Typical values are shown below; actual configuration can be tailored to specific throughput requirements.

Working Principle

In operation, eggs are conveyed on a food‑grade belt to a vision‑guided orientator that rotates each egg to the correct position before gentle mechanical placers drop them into the packaging format.

Key Features

Adjustable lane width for rapid change‑over between egg grades
Soft‑touch placement heads reduce crack rate below 0.2 %
Stainless‑steel frame withstands wash‑down cycles at 80 °C
Modular design allows addition of lanes without line shutdown
Low‑maintenance drivetrain with sealed bearings and self‑lubricating chains

These characteristics translate into reduced labor dependence and consistent pack quality across shifts.

Applications

Poultry farms and integrated egg processing plants benefit from the machine’s ability to maintain hygiene standards while increasing pack line throughput.

Customization Options

Depending on facility layout and product mix, the packing machine can be supplied with various lane counts, ejector types, and control interfaces.

Quality Assurance

Manufacturing follows strict tolerance controls on stainless‑steel thickness and weld integrity, with each unit undergoing a functional run test at 110 % of rated speed before shipment.
